Models: VTR-1022X6 (6-Station) | VTR-1022X12 (12-Station)
Experience exceptional precision and productivity in cement consistency and setting time testing with the Vicatron Series Automatic Vicat Testing Devices by Vector.
Designed for professional cement laboratories, the Vicatron 6x and 12x deliver automated, high-throughput testing that ensures accuracy, repeatability, and full compliance with EN 196-3 and ASTM C191 standards. Choose between 6-station or 12-station configurations to match your testing capacity and workflow requirements.
Key Advantages
✔ Standards Compliance
Meets EN 196-3 and ASTM C191, ensuring reliable and internationally recognised test results.
✔ Multi-Station Efficiency
Select between 6 or 12 test stations for simultaneous multi-sample analysis — ideal for busy laboratories needing maximum throughput.
✔ Precision Measurement
Delivers 0.01 mm penetration depth accuracy with adjustable penetration intervals for total control of testing parameters.
✔ Comprehensive Data Capture
Automatically records initial, final, and false final setting times, providing a complete understanding of cement performance.
✔ Intelligent Software Control
Vector’s advanced control software enables real-time monitoring, automatic data logging, and detailed PDF report generation — complete with operator name, company logo, and archived historical data.
✔ Built-In Safety & Low Maintenance
Includes motion-limit safety sensors, a contactless needle drop system, and automatic needle cleaning to prevent residue build-up and maintain long-term accuracy.
✔ Simple, Secure Operation
Password protection, USB data transfer, and intuitive controls simplify operation and enhance data integrity.
✔ Dependable Support
Delivered with a comprehensive warranty, guaranteed spare parts supply, and ongoing software and technical support for complete peace of mind.
Overview
The Vicatron 6x and Vicatron 12x deliver fully automated, independent station control for testing cement setting characteristics under identical or varied conditions.
Each impact and penetration event is captured in real time with 0.1 mm resolution, while the integrated, temperature-controlled water tank ensures stable, traceable testing conditions for both dry and underwater methods.
User-friendly software allows direct adjustment of needle height, calibration, and testing intervals, offering complete flexibility for both research and routine quality control. Automated cleaning, motion-limit sensors, and precision mechanics minimise maintenance and maximise uptime.
Customisable PDF reports summarise every stage of testing, while unlimited data storage and USB export simplify long-term result management.
Applications
-
Construction & Building Materials: Routine cement quality control and certification
-
Civil Engineering Research: Setting behaviour studies for infrastructure materials
-
Educational Institutions: Academic and training laboratory use
-
Industrial Quality Control: High-volume cement and binder production testing
Technical Specifications
| Specification | Vicatron 6x | Vicatron 12x |
|---|---|---|
| Model Code | VTR-1022X6 | VTR-1022X12 |
| Number of Stations | 6 | 12 |
| Standards Compliance | EN 196-3, ASTM C191 | EN 196-3, ASTM C191 |
| Penetration Depth Accuracy | 0.01 mm | 0.01 mm |
| Needle Weight | 300 g | 300 g |
| Needle Drop Height | Adjustable via software | Adjustable via software |
| Penetration Step Time | 1 – 999 min (dynamic) | 1 – 999 min (dynamic) |
| Testing Environment | Dry or underwater | Dry or underwater |
| Water Tank | Integrated with circulation and drainage | Integrated with circulation and drainage |
| Data Logging | Temperature & penetration depth | Temperature & penetration depth |
| Software Features | Real-time monitoring, PDF reporting | Real-time monitoring, PDF reporting |
| Connectivity | USB | USB |
| Safety Features | Motion-limit sensors, contactless drop | Motion-limit sensors, contactless drop |
| Maintenance | Automatic needle cleaning system | Automatic needle cleaning system |
| Power Supply | 220 V 50 Hz | 220 V 50 Hz |
| Support | Full software & technical support | Full software & technical support |
Summary
The Vicatron 6x and Vicatron 12x Automatic Vicat Testing Devices redefine the standard for precision and productivity in cement testing.
With automated operation, intelligent software control, and robust engineering, they deliver consistent, traceable, and high-quality results — helping laboratories meet the highest standards of accuracy, efficiency, and compliance.
Experience the future of cement setting time analysis — with Vicatron by Vector.
