Industrial Demagnetiser

Industrial Demagnetiser

Efficient demagnetisation for precision inspection and production.

The Industrial Demagnetiser delivers reliable and high-performance demagnetisation for demanding industrial and inspection applications. Designed with high-power demagnetising coils and digitally controlled power modules, the system provides precise, repeatable results for parts requiring controlled removal of residual magnetism — an essential step before magnetic particle inspection (MPI), eddy current testing, or final assembly.

Whether configured for pulse demagnetisation in high-field applications or continuous operation for material flow lines, the demagnetiser ensures efficiency, flexibility, and consistency in every process.

Key Features

• Precision-Controlled Demagnetisation: Digitally guided power modules ensure consistent magnetic field control and reliable demagnetisation results.

• Versatile MPI Integration: Ideal for pre-MPI and post-MPI demagnetization to eliminate residual fields that can affect magnetic particle inspection accuracy.

• Flexible Configurations: Available for both pulse and continuous demagnetisation, adaptable to a wide range of industrial applications.

• Durable Coil Design: Fully encapsulated coils with temperature monitoring, electrical insulation, and protection against overheating for long service life.

• Smart Digital Operation: PLC-controlled with all parameters stored and adjustable digitally; supports manual or remote operation.

• Remote Maintenance: Modern internet-based remote diagnostics and parameter restoration simplify servicing and reduce downtime.

• Custom Solutions: Tailored coil and power module designs available for non-standard part sizes or specific demagnetization requirements.

Typical Applications

• Demagnetising parts before magnetic particle inspection (MPI) or eddy current testing

• Removing residual magnetism from tools, fixtures, and clamping systems

• Preparing components for cleaning, coating, or finishing processes

• Meeting strict residual magnetism limits in precision manufacturing

• Continuous demagnetisation of semi-finished or long steel products

Technical Overview

• Demagnetising Coils:
  Designed for maximum field strength and durability, with standard active areas ranging from 150×100×130 mm to 710×550×210 mm, and custom dimensions available on request.

• Power Modules:
  Options from LM14 to LM120, supporting single- or three-phase AC inputs (200–480V, 16–63A), with digital PLC control and isolated 24V communication for automation systems.

• Operation Modes:
  Pulse or continuous demagnetisation depending on application.

• Maintenance:
  All parameters stored digitally for quick system restoration and global support availability.

The Industrial Demagnetiser is the preferred solution for manufacturers and laboratories seeking accurate, efficient, and traceable demagnetisation before nondestructive testing (NDT), MPI, or precision assembly.

Enhance your inspection accuracy — eliminate residual magnetism..
