Electronic Tensile Tester GBH-2

Vendor
GBPI
Regular price
$0.00
Sale price
$0.00
Regular price
Sold out
Unit price
per

The versatile single-column electronic tensile tester, GBH-2, is an advanced mechanical property testing machine designed to meet the standards of GB, JIS, ASTM, DIN, and other industry requirements. Developed to address market demands, this instrument employs high-precision sensors, ensuring force measurement accuracy within ±0.5 %FS. The loading mechanism utilises high-precision ball screws, offering stable loading and an extended lifespan. Equipped with professional software support, it facilitates fully automatic operation via a color touch screen, providing real-time display of test curves and accessible test reports. This tester is ideal for various tests on both metallic and non-metallic materials, offering capabilities such as tensile, peeling, heat sealing, tearing, puncturing, compression, bending, shearing, and more. It calculates material parameters, including breaking strength and elastic modulus, making it indispensable in industries such as medicine for physical property testing, teaching research, and quality control.

Test Principle The processed sample is fixed between two chucks in the fixture. The instrument initiates relative movement of the chucks, with the force value sensor on the movable chuck collecting force value changes during the test. Simultaneously, the built-in displacement sensor captures changes in displacement to calculate performance indicators such as tensile strength, tear resistance, and deformation rate of the sample.

Tensile Test Principle Diagram [Visualisation of Tensile Test Principle]

Standards GB/T 8946, GB 8808, GB 13022, GB/T 1040, GB 4850, GB/T 7753, GB/T 7754, GB/T 453, GB/T 17200, GB/T 16578.1, QB/T 1130, GB/T 2791, GB/T 2790, GB/T 2792, GB/T 7122, GBT 10004, GB/T 17590, JJG 139, GB/T 6344, GB 10808, YBB 00112003, YBB 00102003, YBB 00132002, YBB 00202004, ASTM D828, ASTM E4, ASTM D882, ASTM D1938, ASTM D3330, ASTM F88, ASTM F904, ISO 37, JIS P 8113, QB/T 2358, etc.

Specifications

  • Test Accuracy: Within ±0.5 %FS of the displayed value
  • Test Speed: 0~500 mm/min (infinitely variable speeds)
  • Travel Distance Range: 750mm (customizable for 1000 mm)
  • Test Width Range: 30 mm (customizable for 50 mm)
  • Displacement Accuracy: Within ±0.5% of the displayed value
  • Instrument Size: L×W×H: 460 mm×525 mm×1430 mm
  • Weight: 86 kg
  • Power Supply: 220 V, 50 Hz

Features

  • Rich Functional Configuration (Customised Services Provided)

    • Basic experiments (stretching, puncturing, peeling, shearing, bending, tearing, heat sealing, mobility, etc.) with the option to equip extensometers.
    • Pharmaceutical package material (metal) experiments, including aluminum cap opening force, plastic removal force, tearing force, and tearing force of tearing sheets.
    • Pharmaceutical package material (plastic) experiments, such as tab opening force, puncture dynamic retention force, puncture force, etc.
    • Medicine package material (pre-filling type) experiments, covering needle tip puncture force, piston activity, body tightness, rubber pad force, needle cap pull-out force, needle-needle seat connection force, etc.
  • Professional Program, Worry-Free and Safe Operation

    • Intelligent safety protection functions, including limit protection, overload protection, automatic return, and emergency stop, ensuring the safety and reliability of the test process.
    • Free unit switching, allowing flexible setting of parameters such as test speed, sample size, and fixture distance. Special test parameters can also be freely configured to meet customer needs.
  • Advanced Configuration, Advanced Technology

    • Equipped with a high-precision force sensor for measurement accuracy of 0.5; high sampling rate (100 times/second) for more accurate test data.
    • High-precision ball screw loading mechanism for stable loading and extended testing machine lifespan, ensuring long-term stability and energy efficiency.
    • Load/deformation measurement with multiple sub-channels, supporting extended measurement with multiple sensors; wide speed range suitable for high and low-speed tests.
  • Diversified Fixture Applications

    • Different sample fixtures can be configured based on customer needs, including fixtures and pneumatic fixtures, allowing for multi-scenario testing.
  • Intelligent Operating System

    • According to the computer system design of the new version of GMP appendix, flexible setting of test process parameters and audit trail functions (test tracking, log tracking) for data traceability, ensuring security and integrity of test data. System operation authority can be set to different levels.
    • Intelligent statistical analysis supporting standard deviation analysis of multiple data. The system is expandable, such as integration with laboratory LIMS systems.
    • Personalized test reports can be set as needed, supporting data output in multiple formats. It can be tested independently from the computer, with the built-in micro-printer printing data in real-time. The instrument has a computer interface for online testing.
  • Lab Intelligent IoT Platform

    • Connects to the IoT platform for network digital management.
    • Allows remote login to the IoT platform, facilitating remote operation and viewing of experimental data.
    • Enables unified management of experimental data for all instruments in the IoT platform.
    • Realizes a complete laboratory management process, with one-click applications for after-sales service and subscription for accessories.
    • Facilitates remote after-sales service through the system, with complete after-sales records on the platform.

Application

  • Plastic Film: Suitable for tensile, peeling, heat sealing, tearing, puncturing, compression, bending, and other performance tests of plastic films, composite materials, flexible packaging materials, tapes, and other products.
  • Composite Film Bag: Applicable to tensile, peeling, heat sealing, tearing, puncture, compression, bending, and other performance tests of composite films, co-extruded films, composite bags, retort bags, aluminum-plastic composite bags, and other products.
  • Paper: Suitable for tensile strength, peeling, deformation, tearing, heat sealing, bonding, and other performance tests of paper, kraft paper, facial tissue, toilet paper, and other products.
  • Medical Patches: Designed for tensile strength, peeling, deformation, tearing, heat sealing, bonding, and other performance tests of medical cold compresses, plasters, and other products.
  • Pressure Sensitive Tapes: Appropriate for tensile strength, peeling, deformation, tearing, heat sealing, bonding, and other performance tests of cellophane tape, electrical insulating tape, medical zinc oxide adhesive tape, and other products.
